The Marantz Model M4 is an 8-channel, four-zone distribution streaming amplifier engineered to deliver superb high-resolution Marantz sound throughout your entire home. Rack-mountable, fan-cooled, and powered by four independent HEOS streaming modules, the Model M4 brings audiophile-grade amplification and modern wireless streaming to four independently controllable zones, making whole-home multi-room audio effortless for music lovers and custom installers alike.
The Marantz Model M4 is an innovative, intelligent take on traditional distribution amplifier designs. With 8 channels of 100W amplification split into four independent zones, the Model M4 delivers no decrease in power even with all channels driven, giving you complete control over four separate rooms from a single chassis. Each zone has its own dedicated HEOS streaming module, analog input, USB-A input, and subwoofer output, so every room can play something completely different at the same time.
Four built-in HEOS modules let you stream your favorite music or TV audio independently or grouped across four different rooms. Use HEOS in up to 24-bit / 192 kHz PCM and DSD quality, or stream via Apple AirPlay 2, Spotify Connect, or Bluetooth from any compatible device. The Model M4's TV Grouping feature lets you stream the same TV audio across connected rooms seamlessly, perfect for game day or whole-home entertaining.
The Model M4's industrial design complements the latest generation of Marantz hi-fi and AVR products, making it more than attractive enough to leave out in the open. Its rack-mountable design also makes it ideal for discreet installations where electronics are kept out of sight in a central AV closet. Twin Ethernet connections, IP control, RS-232, and 12V triggers ensure the Model M4 integrates cleanly into any custom installation control platform.
| Configuration | 8 channels, 4 zones (stereo per zone) |
| Amplifier topology | Class D |
| Power output (8 ohms) | 8 x 100W (20 Hz – 20 kHz, 0.05% THD) |
| Power output (4 ohms) | 8 x 125W (1 kHz, 0.1% THD) |
| Bridge mode | Up to 4 x 200W |
| Speaker impedance | 4–8 ohms |
| Streaming resolution | Up to 24-bit / 192 kHz PCM and DSD via HEOS |
| Audio inputs | 4 x RCA Stereo Analog, 2 x Optical, 4 x USB-A |
| Outputs | 4 x Stereo Speaker Out, 4 x Stereo Pre-Out, 4 x Mono Subwoofer Out |
| Streaming protocols | HEOS Built-in, Apple AirPlay 2, Spotify Connect, Bluetooth |
| Network | 2 x Ethernet, Dual-band Wi-Fi |
| Control | HEOS app, IP / TCP-IP, RS-232, 4 x 12V triggers |
| Form factor | Rack-mountable, fan-cooled |
Each of the Model M4's four zones has its own dedicated HEOS streaming module, meaning four different family members can stream four completely different sources to four different rooms at the same time. HEOS supports a comprehensive list of music services including TIDAL (with HiRes), Spotify, Amazon Music HD, Deezer HiFi, Qobuz, SoundCloud, TuneIn, Pandora, SiriusXM, iHeartRadio, and more.
When a particular zone needs more grunt — large speakers in a great room, outdoor speakers, or a demanding home theater pair — the Model M4's Bridge Mode combines channel pairs to deliver up to 4 x 200W per zone, ensuring you have the headroom to drive even demanding loudspeakers in larger rooms.
The Model M4 includes four switchable mono subwoofer outputs with adjustable high-pass and low-pass filters (40–250 Hz / 40–120 Hz), letting you add a powered subwoofer to any or all four zones for room-filling, extended bass. Independent filtering per zone means every room is properly tuned for its speakers and dimensions.
Four assignable stereo pre-outs let you bypass the onboard amplification and connect external power amplifiers in any zone, perfect for rooms with very demanding speakers or for installations where the M4 acts as the streaming and control brain for larger amplifier stacks downstream.
Two optical inputs with onboard Dolby Digital decoding allow you to integrate TV audio into the multi-zone system. Stream TV audio from the main room to every connected zone using the TV Grouping feature, ideal for sports, news, or major broadcasts during gatherings.
MMDF is Marantz's proprietary digital filtering technology, engineered to reveal the natural detail and tonality in digital sources. Applied across every input on the Model M4, MMDF ensures streamed, optical, and USB sources retain the musicality Marantz has been known for over decades of hi-fi design.
Each zone can be tailored independently with bass and treble controls (±5 dB), balance (±15 dB), volume limiting, and a selection of sound modes including Stereo, Direct, Virtual, Dialog Enhancer, and Night, so every room sounds its best for whatever's being listened to and whenever it's being listened to.
Designed for custom installation, the Model M4 supports control via the HEOS app, IP / TCP-IP control for popular integration platforms (Control4, Crestron, Savant, RTI, ELAN), RS-232, and four 12V triggers. Twin Ethernet connections provide network redundancy and clean integration into structured wiring.
As a HEOS-enabled device, the Model M4 can share music with existing Marantz hi-fi and AVR components, additional Model M4 units, or Marantz Model M1 streaming amps, expanding your multi-zone system across as many rooms as you need.
