The DU9053Z is a 21,000 ANSI lumen WUXGA laser projector for rental, staging and large venue applications. Its Constant Brightness function monitors light output for installations that need consistent matching between projectors.
An interchangeable lens system covers different projection distances, with network and HDBaseT connections for the AV system. Lenses are optional accessories; use the DU9053Z lens group for the verified part numbers.
| ITEM | DESCRIPTION |
|---|---|
| Image format | WUXGA (1920 x 1200) |
| Brightness | 21000 ANSI Lumens |
| Projection optics | 7 optional lenses from 0.38:1 to 10.3:1 throw ratio range |
| Source connections | HDMI Number of Ports (2x), Display Port , DVI-D , Component (5 BNC) (RGBHV) , Remote Jack(wire remote) , 3G-SDI (2x: In and Out), RS-232 (1x), 3D-Sync (2x: In and Out), USB A (1x with Power ), RJ45 (1x: HDBaseT/LAN) |
HDMI Cable , Remote Control Cable , AC Power Cord , Lens Cap , Warranty Card (by region) , Remote Controller (with battery)
| DETAIL | VALUE |
|---|---|
| Native Resolution | WUXGA (1920 x 1200) |
| Brightness | 21000 ANSI Lumens |
| Contrast Ratio | 3 000 000:1 (Dynamic) |
| Native Aspect Ratio | 16:10 |
| Display Type | DLP Technology by TI |
| Chip Size | Single Chip 0.96'' DMD |
| Throw Ratio | 7 optional lenses from 0.38:1 to 10.3:1 throw ratio range |
| Zoom Ratio | Motorized Zoom & Focus |
| Projection Distance | Depending on lens selection |
| Image Size (Diagonal) | Depending on lens selection |
| Lens Shift Range | Lens Shift Range (Vertical: +/-50%; Horizontal: +/-15%) |
| Keystone Correction | Vertical: +/-40 Steps; Horizontal: +/-45 Steps |
| I/O Connection Ports | HDMI Number of Ports (2x), Display Port , DVI-D , Component (5 BNC) (RGBHV) , Remote Jack(wire remote) , 3G-SDI (2x: In and Out), RS-232 (1x), 3D-Sync (2x: In and Out), USB A (1x with Power ), RJ45 (1x: HDBaseT/LAN) |
| Dimensions (W x D x H) | 676.6 x 598.8 x 270mm |
| Weight | 45.4 kg |
| Noise Level | 43dB / 40dB (Normal / Eco) |
| Power | Supply: AC 100-240V, 50/60Hz Consumption: 1300W (Normal Mode) <0.5W (Standby) |
Have a question about this product or want help matching it to your space? Send the item through and our team will respond with the right advice.
