The DU7199Z provides 9,000 ANSI lumens at WUXGA resolution for large venue projection. Interchangeable motorised lenses offer different throw distances rather than a single fixed installation range.
Lens memory supports saved positions, while HDBaseT and network connectivity suit integrated AV systems. Select a compatible lens from the model-specific lens group; lenses are optional accessories. This offer is the black version.
| ITEM | DESCRIPTION |
|---|---|
| Image format | WUXGA (1920 x 1200) |
| Brightness | 9000 ANSI Lumens |
| Projection optics | 9 optional lenses from 0.50:1 to 8.3 :1 throw ratio range |
| Source connections | VGA-In (15pin D-Sub) , HDMI Number of Ports v.2.0 (x2), DVI-D , Component (5 BNC) (RGBHV) , USB B (Service), Remote Jack(wire remote) , RS-232 (x2: In and Out), 3D-Sync (x2: In and Out), USB A (Power Only), VGA-Out (15pin D-Sub) , Audio-Out (RCA) , RJ45 (x2: LANx1, HDBaseTx1), Composite Video , Audio-In (RCA) , Audio-In (Mini-Jack) |
VGA Cable , AC Power Cord , Lens Cap , Quick Start Guide , Warranty Card (by region) , Remote Controller (with battery)
| DETAIL | VALUE |
|---|---|
| Native Resolution | WUXGA (1920 x 1200) |
| Brightness | 9000 ANSI Lumens |
| Contrast Ratio | 3,000,000:1 (Full On/Off) |
| Native Aspect Ratio | 16:10 |
| Display Type | Single chip DLP® Technology by Texas Instruments |
| Chip Size | 0.67” DMD |
| Lamp Life and Type | Lamp free design. Laser light source lasts up to 20,000 hours |
| Throw Ratio | 9 optional lenses from 0.50:1 to 8.3 :1 throw ratio range |
| Zoom Ratio | Motorized |
| Lens Shift Range | Lens Shift Range (Vertical: Bottom 50% to Top 70%, Horizontal: Left 15% to Right 15%) |
| Keystone Correction | Vertical +/-30°; Horizontal +/-30° |
| Speakers | 10 W x2 |
| I/O Connection Ports | VGA-In (15pin D-Sub) , HDMI Number of Ports v.2.0 (x2), DVI-D , Component (5 BNC) (RGBHV) , USB B (Service), Remote Jack(wire remote) , RS-232 (x2: In and Out), 3D-Sync (x2: In and Out), USB A (Power Only), VGA-Out (15pin D-Sub) , Audio-Out (RCA) , RJ45 (x2: LANx1, HDBaseTx1), Composite Video , Audio-In (RCA) , Audio-In (Mini-Jack) |
| Dimensions (W x D x H) | 470 x 517 x 202mm |
| Weight | 20.6 kg |
| Noise Level | 35dB/33dB (Normal/Eco. Mode) |
| Power | Supply: AC 100-240V, 50/60Hz Consumption: 540W (Normal Mode), <0.5W (Standby) |
| Colour | Black |
Have a question about this product or want help matching it to your space? Send the item through and our team will respond with the right advice.
