The DU7099Z is an 8,000 ANSI lumen WUXGA laser projector for large venue installations. Its interchangeable lens system lets the installer select optics for the projection distance and screen layout.
Motorised lens adjustment and lens memory support installation setup. HDBaseT and network connectivity provide links to the wider AV system. Projection lenses are optional accessories and are listed separately. This offer is the black version.
| ITEM | DESCRIPTION |
|---|---|
| Image format | WUXGA (1920 x 1200) |
| Brightness | 8000 ANSI Lumens |
| Projection optics | 9 optional lenses from 0.50:1 to 8.3 :1 throw ratio range |
| Source connections | VGA-In (15pin D-Sub) , HDMI Number of Ports v.2.0 (x2), DVI-D , Component (5 BNC) (RGBHV) , USB B (Service), Remote Jack(wire remote) , RS-232 (x2: In and Out), 3D-Sync (x2: In and Out), USB A (Power Only), VGA-Out (15pin D-Sub) , Audio-Out (RCA) , RJ45 (x2: LANx1, HDBaseTx1), Component (YPbPr BNC x 3) , Composite Video , Audio-In (RCA) , Audio-In (Mini-Jack) |
VGA Cable , AC Power Cord , Quick Start Guide , Warranty Card (by region) , Remote Controller (with battery)
| DETAIL | VALUE |
|---|---|
| Native Resolution | WUXGA (1920 x 1200) |
| Brightness | 8000 ANSI Lumens |
| Contrast Ratio | 3,000,000:1 (Full On/Off) |
| Native Aspect Ratio | 16:10 |
| Display Type | Single chip DLP® Technology by Texas Instruments |
| Chip Size | 0.67” DMD |
| Lamp Life and Type | Lamp free design. Laser light source lasts up to 20,000 hours |
| Throw Ratio | 9 optional lenses from 0.50:1 to 8.3 :1 throw ratio range |
| Zoom Ratio | Motorized |
| Lens Shift Range | Lens Shift Range (Vertical: Bottom 50% to Top 70%, Horizontal: Left 15% to Right 15%) |
| Keystone Correction | Vertical +/-30°; Horizontal +/-30° |
| Speakers | 10W x 2 |
| I/O Connection Ports | VGA-In (15pin D-Sub) , HDMI Number of Ports v.2.0 (x2), DVI-D , Component (5 BNC) (RGBHV) , USB B (Service), Remote Jack(wire remote) , RS-232 (x2: In and Out), 3D-Sync (x2: In and Out), USB A (Power Only), VGA-Out (15pin D-Sub) , Audio-Out (RCA) , RJ45 (x2: LANx1, HDBaseTx1), Component (YPbPr BNC x 3) , Composite Video , Audio-In (RCA) , Audio-In (Mini-Jack) |
| Dimensions (W x D x H) | 470 x 517 x 202mm |
| Weight | 20.6 kg |
| Noise Level | 33dB/31dB (Normal/Eco. Mode) |
| Power | Supply: AC 100-240V, 50/60Hz Consumption: 465W (Normal Mode), <0.5W (Standby) |
| Colour | Black |
