Twin C-CAM bass drivers, twin ABR s (Auxiliary Bass Radiators) and a single C-CAM tweeter in the centre section to provide the SB-3 with higher acoustic output and power handling for critical centre channel reproduction. This is combined with individual mid-bass, tweeter and sealed ABR drivers for both left and right channels.
In larger rooms the SB-3 can be used with a partnering Monitor Audio subwoofer to deliver the best possible audio experience. Within smaller environments and systems, the SBs will deliver effortless full range audio way beyond the limits of any TV's sound system.
It suits a screen wall where the visual brief is restrained but the audio system is still expected to behave like one.
For official product information and current support resources, visit the Monitor Audio SB3 Soundbar product page.
| ITEM | DESCRIPTION |
| Main Features | |
| C-CAM driver technology | Monitor Audio’s ceramic-coated aluminium magnesium diaphragms combine low mass with controlled rigidity. |
| Passive LCR architecture | Separate left, centre and right channels preserve dialogue focus and screen-wide steering from one cabinet. |
| Screen-focused channel layout | Keeps dialogue and front-stage effects closely connected to the picture. |
| Living-room integration | A low-profile format intended to preserve a clean television installation. |
| DETAIL | VALUE |
| Product Specifications | |
| Frequency Response (-3 dB) | All Channels: 80 Hz – 30 kHz |
| Sensitivity (1W@1M) | Left and Right Channels: 84 dB Centre Channel: 87 dB |
| Nominal Impedance | 8 ohms |
| Power Handling (RMS) | Left and Right Channels: 40 W Centre Channel: 80 W |
| System Power Handling (RMS) | All Channels: 100 (High pass filter set to 100 Hz) |
| Recommended Amplifier Requirements | All Channels: 30 — 100 W |
| Crossover Frequency | All Channels: 80 — 120 Hz |
| Maximum SPL | 104 (108.8 all channels driven) dBa |
| Bass Alignment | Auxiliary Bass Reflex (ABR) Loading |
| Drive Unit Complement | Left and Right Channels: 2 × 4" (100 mm) C-CAM cone bass/mid driver, 2 × 1" (25 mm) C-CAM Gold Dome tweeter Centre Channel: Left and Right Channels: 2 × 4" (100 mm) C-CAM cone bass/mid driver, 1 × 1" (25 mm) C-CAM Gold Dome tweeter |
| Cabinet Dimensions: (H x W x D) (Including Feet) | 145 × 1310 × 89 mm (5^11/16 × 51^9/16 × 3^1/2") |
| External Dimensions (Including Bracket (H x W x D)) | 145 × 1310 × 100 mm (5^11/16 × 51^9/16 × 3^15/16") |
| Bracket | BSB |
| Weight | 9.1 kg (20 lb) |
| Sold As | Single Unit |
| Best Suited For | |
| Living-room television systems where a clean screen wall and focused front stage are priorities. | |
Have a question about this product or want help matching it to your space? Send the item through and our team will respond with the right advice.
