The SACD 10 is a disc player built at a point when most makers have stopped building them. It exists because a great many serious music collections still live on silver discs rather than on a server.
Its transport mechanism is the part that justifies the engineering. Resonance control in a spinning disc reader is what keeps the mechanism reading cleanly rather than correcting, and that job gets harder as a disc ages.
Beyond discs it accepts external digital sources over coaxial, optical and USB, so a streamer or a computer can borrow its conversion stage. Native support extends to high-rate DSD and PCM material.
Distortion and noise figures are low enough that the disc itself sets the limit rather than the player reading it. The balanced output feeds a partnering preamplifier without an extra conversion in the path. That is the point of building a source this capable into a reference system.
Marantz SACD 10 official product page
| ITEM | DESCRIPTION |
|---|---|
| Dedicated SACD transport | A mechanism engineered against resonance rather than adapted from a drive. |
| SACD and CD playback | Both disc formats read natively rather than through conversion. |
| Digital inputs | External sources can borrow the conversion stage over coaxial, optical or USB. |
| High-rate format support | Native handling of high-rate DSD and PCM material. |
| Balanced analogue output | Feeds a partnering preamplifier without extra conversion. |
| DETAIL | VALUE |
|---|---|
| Disc transport | Marantz SACDM-3 transport mechanism |
| Supported discs | SACD and CD |
| Digital format support | DSD 256 and PCM 384 / 32 |
| Conversion | MMM-Conversion with HDAM output circuit |
| Optical connections | 2 inputs, 1 output (4.1 - 192 kHz max) |
| Coaxial connections | 2 inputs, 1 output (4.1 - 192 kHz max) |
| Usb inputs | USB-A and USB-B DAC inputs |
| Analogue outputs | Fixed RCA unbalanced 2.0 Vrms; Fixed XLR balanced 4.0 Vrms |
| Headphone output | 130 mW at 32 ohms |
| Frequency response | SACD 2 Hz - 50 kHz (-3dB); CD 2 Hz - 20 kHz (±1.0 dB) |
| Total harmonic distortion | SACD 0.0004 %; CD 0.0015 % |
| Signal-to-noise ratio | SACD 118 dB; CD 116 dB |
| Dimensions | 440 x 192 x 442 mm |
| Weight | 33.0 kg |
| ITEM | QUANTITY |
|---|---|
| SACD 10 disc player | 1 |
