| DETAIL |
VALUE |
| Product Specifications |
| Frame or bezel |
The MP-60 2.1 supports Variable refresh rate (VRR), Quick Frame Transport (or Fast Vactive), and auto low latency mode (ALLM) support and high dynamic range (HDR) metadata passthrough for HDMI dynamic HDR, HDR10+, and Dolby Vision™ |
| Inputs |
With five HDMI inputs and two outputs, this new masterpiece from Lyngdorf Audio now supports HDMI 2.1 including features eARC, Dynamic Lip-Sync and QMS (Quick Media Switching) as well as the latest decoding and post-processing formats |
| Connectivity |
State-of-the-art HDMI processing The MP-60 2.1 processor is intuitive to use and offers extraordinarily easy installation |
| Audio format support |
The MP-60 2.1 offers full support of the latest immersive surround formats including Dolby Atmos®, DTS:X® Pro and AURO-3D® |
| Resolution |
Swiping left and right gives you access to cover art as well as informing you of the signal resolution |
| Microphone system |
Specifications RoomPerfect microphone, Microphone stand, Microphone cable, RF remote control State-of-the-art HDMI processing |
| Channels |
It decodes up to 16 native audio channels which can be mapped out intelligently through the sleek website interface |
| Network and control |
Control the MP-60 2.1 with an app The “Lyngdorf Remote” app automatically discovers the MP-60 2.1 connected to your local network, and you will be able to adjust all the basic functions like input selection and volume level from your handheld device |
| Decoding |
: 16 decoding/upmixing channels, Dolby Atmos®, DTS:X Pro (14 channels), AURO-3D® (14 channels), all legacy codecs |
| Post processing options |
Dolby Surround, AURO-MATIC®, DTS Neural:X |
| Audio inputs |
5 x HDMI (1 x HDMI eARC) ≤192kHz/24bit, 1 x AES/EBU S/P-DIF input (≤192kHz/24bit), 3 x S/P-DIF coaxial inputs (≤192kHz/24bit), 4 x S/P-DIF optical inputs (≤96Hz/24bit), 1 x USB audio input (≤192kHz/32bit), 1 x microphone input (XLR) for RoomPerfect™ |
| Audio outputs |
16 x XLR analog outputs (8 Vrms max.), 1 x SPDIF coax digital ZONE output (Fix 96kHz/24bit) |
| Audio specifications |
Frequency response: ±0,5dB from 20 to 20,000 Hz, Total harmonic distortion: 0.005% max from 20 to 20,000 Hz |
| EQ |
RoomPerfect, Subwoofer level assistant, 32 x adjustable voicings holding ≤8 shelving, high/low pass or parametric filters with adjustable gain and Q |
| Media player |
Internet radio (vTuner, airable), AirPlay 2, Spotify Connect, Tidal Connect with Dolby Atmos Music, Roon Ready, DLNA Support of FAT32 based media storage (uPnP/ see DLNA formats ) |
| Video inputs |
5 x HDMITM (2.1, HDCP 2.3), accepts 8k30 RGB/YCbCr 4:4:4 10-bit video, 8k60 YCbCr 4:2:0 10-bit high definition video, and 4k120 4:4:4 10-bit high frame rate video, Variable refresh rate (VRR), fast vactive (FVA), and auto low latency mode (ALLM) support. accepts HDR, Dolby VisionTM and HLG |
| Video outputs |
2 x HDMI (HDCP 2.3) |
| Video scaling |
Upscaling of all video to 4K ultra high definition, no downscaling of 4K video |
