| DETAIL |
VALUE |
| Amplifier |
| Power Amplifier Rated output & THD (8ohm) |
100 W+100 W (8 Ω/ohms, 20 Hz to 20 kHz, T.H.D. 0.05 %) |
| Power Amplifier Rated output & THD (4ohm) |
125 W + 125 W (4Ω/ohms, 1 kHz, T.H.D. 0.1%) |
| Frequency Response |
20 Hz to 20 kHz : ±1.5 dB |
| Connected loudspeaker Impedance |
4 – 16 Ω/ohms |
| Audio Inputs / Outputs |
| Loudspeaker Binding Posts |
4-way binding posts |
| Digital Inputs |
HDMI (eARC), TOSLINK |
| Analog Inputs |
RCA L/R |
| Subwoofer Out |
RCA Mono |
| Audio Options |
| Channel Assignments |
Stereo (Default), Dual Mono |
| Volume Limit |
80-100% |
| Balance |
-15dB to +15dB |
| Adjustable High Pass / Low Pass Filters |
40-250 Hz / 40-120 Hz |
| EQ |
Bass, Treble -5dB to +5dB |
| Sound Modes |
Stereo, Direct, Virtual, Denon Dialog Enhancer, Night Mode |
| TV Sound Grouping |
Yes |
| Audio Format Support |
| Decoding |
Dolby Digital +, Dolby Digital, LPCM, DSD |
| Stereo PCM / Multi-channel PCM |
Yes / Yes |
| Stereo File Formats (HEOS network share or USB) |
WMA: up to and including 192 kbps AAC & MP3: up to and including 320 kbps WAV, ALAC, FLAC: up to and including 24-bit/192kHz DSD: 2.8 MHz, 5.6MHz |
| Streaming Technologies |
| Bluetooth Receive |
BT 4.2 |
| AirPlay |
Airplay 2 |
| Roon |
Roon Ready |
| Spotify |
Spotify Connect |
| Music Services and Sources |
| Music Services Supported (HEOS, subject to change and local availability) |
Pandora, Spotify, TuneIn, SiriusXM, Amazon Music, Tidal, Tidal HiRes, iHeartRadio, Deezer, Deezer HiFi, Mood:Mix, Sony Hi-Res, AWA, QPlay, SoundCloud. |
| Music stored on mobile device |
Yes (iOS, Android or Kindle Fire) |
| NAS (Network Attached Storage) |
Network share, DLNA |
| USB Storage Device Playback |
Yes (FAT32, NTFS formatted drives) |
| Networking & Control |
| Wired Connectivity |
Ethernet |
| Wireless Connectivity |
Dual band, 802.11 a/b/g/n/ac |
| IR Input |
3.5mm |
| IR Learning |
Yes |
| Control System Compatibility via TCP/IP |
Crestron, Control4, AMX |
| HEOS App |
iOS, Android, Kindle Fire |
| General |
| Product Color |
Black |
| User Interface |
Volume up/down, Play / Pause, Quick Select 1/2/3, Multi colored LED status indicator, Connect button (rear), Bluetooth button (rear) |
| Dimensions (H x W x D) Inches |
3.4 x 8.54 x 9.21 Inches |
| Dimensions (H x W x D) mm |
86.2 x 217 x 234mm |
| Weight (lbs) |
4.5 pounds |
| Weight (kg) |
2 KG |
