Anthem MDX-12 Distribution Amplifier
The MDX-12 is a distribution amplifier, which means it exists to feed many rooms rather than to impress in one. Twelve channels of music from a single rack unit is the whole proposition.
Channels can be bridged in pairs where a zone needs more than its share, so a main living space and a bathroom can run from the same chassis without either being compromised for the other.
Six dedicated inputs give each zone its own source, and two global inputs cover the material that should play everywhere at once. That split is what distributed audio actually needs day to day.
Distortion stays low across all twelve channels, and load monitoring watches each one independently. For a rack that nobody visits between service calls, reliability counts for far more than headline power, and this is a chassis built to be forgotten about.
Anthem MDX-12 official product page
Main Features
| ITEM | DESCRIPTION |
|---|---|
| Twelve channels in one rack unit | A full distributed system in a single rack space. |
| Bridgeable channel pairs | More output for a zone that needs it, from the same chassis. |
| Per-zone and global inputs | Six dedicated inputs plus two that play everywhere. |
| Load monitoring per channel | Each channel protected and watched independently. |
| Efficient power supply | Up to a kilowatt available from a compact single-height chassis. |
Specifications
| DETAIL | VALUE |
|---|---|
| Power output | 75W x 12 channels at 8 ohms, up to 150W x 12 channels at 4 ohms |
| Bridged output | 280W at 8 ohms |
| Channels | 12 channels |
| Total harmonic distortion | 0.002 % |
| Inputs | Six dedicated analogue inputs, one per zone, plus two selectable global analogue inputs |
| Rack height | Single 1U rack space |
| Power supply | Up to 1,000 watts |
| Protection | Advanced Load Monitoring (ALM) with channel bridging |
| Cooling | Fan cooled 1U chassis |
Included Items
| ITEM | QUANTITY |
|---|---|
| MDX-12 amplifier | 1 |
